Product Description
The CD50 PV Panel Cleaning Drone is an intelligent aerial cleaning solution designed for utility-scale solar farms, commercial and industrial rooftops, and residential photovoltaic systems. Equipped with a 50L water tank, high-pressure cleaning system, dual RTK centimeter-level positioning, and intelligent autonomous flight control, it delivers safe, efficient, and fully automated PV panel cleaning. The modular design supports multiple spray nozzle options to meet different cleaning requirements while reducing labor costs and improving cleaning efficiency. The CD50 is the ideal solar panel cleaning drone, PV cleaning solution, and drone cleaning system for modern photovoltaic operation and maintenance (O&M).
Product Advantage
Smart Photovoltaic Maintenance Solution
The CD50 is an advanced solar panel cleaning drone designed for efficient photovoltaic maintenance. Equipped with a high-pressure cleaning system and intelligent operation modes, it helps solar farms reduce manual labor costs, improve cleaning efficiency, and maintain optimal power generation performance.
Keywords: Solar Panel Cleaning Drone, Photovoltaic Cleaning Drone
Precise and Stable Flight Control
Featuring a dual RTK positioning system, the CD50 achieves centimeter-level flight accuracy for safe and precise solar panel cleaning. The advanced navigation technology ensures stable operation, accurate route tracking, and reliable performance in complex outdoor environments.
Keywords: Dual RTK Drone, Precision Cleaning Drone
Automatic Cleaning Operation
The CD50 integrates intelligent route planning and autonomous flight technology. Operators can easily set cleaning paths, allowing the drone to complete photovoltaic cleaning tasks automatically. This reduces operation difficulty and improves maintenance efficiency for large-scale solar power plants.
Keywords: Automatic Cleaning Drone, Smart Solar Cleaning System
High-Pressure Washing Technology
Designed for professional PV panel cleaning, the CD50 effectively removes dust, sand, and surface contaminants with its high-pressure water cleaning system. It is ideal for solar farms, industrial photovoltaic projects, and large-scale solar maintenance applications.
Keywords: High Pressure Cleaning Drone, Solar Farm Maintenance Drone
Professional Industrial Drone Solution
The CD50 is equipped with multiple safety protection systems to ensure stable operation during outdoor missions. Combined with intelligent flight control and reliable communication technology, it provides a complete commercial solar cleaning drone solution for global photovoltaic maintenance companies.
Keywords: Commercial Cleaning Drone, Industrial Drone Solution
Technical Parameters
Basic Parameters | CD50 |
Folded Size | 1350×720×820 mm |
Expanded Size (Propeller Unfolding) | 3195×2990×825 mm |
Wheelbase | 2300mm |
Number of Rotors | 4 |
Tank Capacity | 50L |
Battery | 18S 30000 mAh |
Working Temperature | -10 °C ~ 40 °C |
Charging Time | 30 min (slow) / |
Spray & Cleaning Settings | |
Spray Flow Rate | 11 L/min |
Rated Water Pressure | 15 MPa |
Cleaning Effciency Per Minute | 34.5㎡ |
Cleaning Area Per Sortie | 138 ㎡ |
Cleaning Effciency Per Hour | 690 ㎡ |
Nozzle Modes | 2 sets swing nozzles + 6-nozzle boom |
Flight Parameters | |
Flight Time (No Payload) | 22min |
Flight Time (Full Payload) | 7min |
Flight Speed | 5-15m/s |
Maximum Takeoff Weight | 105kg |
Positioning | Dual RTK |
Obstacle Avoidance | Radar intelligent perception |
